406A913
Rigel 288+ Electrical Safety Analyser
Electrical Safety Analyzers
- Compact and lightweight design
- Full compliance to international and local safety standards IEC/EN 62353, AAMI/IEC/EN
- 60601-1, IEC 61010, NFPA-99 and AS/NZ 3551
- Battery powered earth/ground bond, insulation and leakage testing
- Additional 50V and 100V DC insulation tests for low voltage equipment
- Accurate high current, low energy earth bond testing
On-Board Storage
Storage for test records, and customizable sequences and codes
Portability with Battery Powered Tests
Lightweight and portable with battery-powered testing
International & Local Testing Standards
IEC/EN 62353, AAMI/IEC/EN 60601-1, IEC 61010, NFPA-99, AS/NZ 3551
Accurate and reliable earth continuity testing
Features a high current low power zap circuit
The Rigel 288+ electrical safety analyzer
The Rigel 288+ electrical safety analyzer provides a fast, reliable, and highly accurate solution for testing the electrical safety of medical devices to both international and local standards, including IEC 60601 and 62353.
Designed for flexibility and ease of use, the Rigel 288+ allows complete freedom of movement thanks to its battery-powered operation. There’s no need for a mains connection, which makes it perfect for testing in clinical settings, on the move, or in hard-to-reach areas. Powered by standard AA batteries, the device supports a wide range of essential tests, including insulation resistance, earth/ground bond, and touch or point-to-point leakage current measurements.
Compact, portable, and easy to operate, the Rigel 288+ is ideal for routine safety checks, maintenance tasks, and field service work, making it a trusted tool for biomedical engineers worldwide.
Request a quote
Our team of sales advisors are on hand to help you with any queries you have about our Rigel 288+ Electrical Safety Analyzer.
Why choose the Rigel 288+ electrical safety analyzer
- Test to IEC/EN 62353, AAMI/IEC/EN 60601-1 & more
- Built-in electronic data storage
- Flexible user-definable test routines
- Battery-powered leakage, insulation & earth/ground bond tests
- 50/100/250/500V DC insulation testing
- Automatic secondary verification ensures the correct result first time
- Small & compact with direct printing via Bluetooth connectivity
- Available in a wide range of power configurations
- Compatible with Med-eBase for simple asset management
Watch the Rigel 288+ overview video
In this short video, Michael Walton, Applications Engineer at Rigel medical covers the main features of the Rigel 288+ Electrical Safety Analyzer and shows how it can test to both IEC 60601 and IEC 62353.
Optional Accessories
288+/62353+ power
cords
Accessories
Test n Tag
Elite 2 Printer
Accessories
Bluetooth Elite
Scanner
Accessories
Patient applied part module
Accessories
Request a Quote
Our team of sales advisors are on hand to help you with any queries you have about our products.
Technical Specifications
| Earth Continuity | |
|---|---|
| Method | 2 wire technique, using ‘zero’ lead function. |
| Test Current | >+200mA, -200mA DC into 2 ohms |
| Max Test Voltage | 4-24V RMS o/c |
| Measuring Range (low range) | 0.001 – 0.999 ohms @ 0.001 ohms resolution |
| Measuring Range (mid range) | 1.00 – 9.99 ohms /@ 0.01 ohms resolution |
| Measuring Range (high range) | 10.0 – 19.9 ohms @ 0.1 ohms resolution |
| PASS/FAIL Threshold | 0.2Ω |
| Accuracy | ± 3% of reading + 10 m ohms |
| Insulation Resistance | |
|---|---|
| Measurement | EUT to earth/ground, EUT to AP, AP to earth/ground |
| Voltage | 50 / 100 / 250 & 500V DC @1mA |
| Range (low range) @ 50V DC | 0.01Mohms – 10 Mohms |
| Range (low range) @ Above 50V DC | 0.01Mohms – 20Mohms |
| Accuracy (low range) | ± 5% of reading +2 counts |
| Range (high range) @ 250V DC | 20Mohms – 50Mohms |
| Range (high range) @ 500V DC | 20Mohms – 100Mohms |
| Accuracy (high range) | ±10% +2 counts |
| Resolution | 0.01Mohms |
| Direct Leakage Measurement | |
|---|---|
| Measuring Range | 4μA to 9999μA |
| Accuracy | ± 5% or reading +2 counts |
| Mains on A.P. voltage | F-type only @ 110% of mains |
| Measuring Device | As per IEC 60601-1 requirements |
| Measurement Type | Separate AC & DC for Patient (Auxiliary) Leakage to IEC 60601, True RMS for all remaining Leakage tests |
| Differential Leakage Measurement | |
|---|---|
| Measuring Range | 75μA to 9999μA |
| Accuracy | ±5% of reading + 5 counts |
| Measurement / display resolution | 1μA |
| Measurement Type | True RMS |
| Measuring Device | Frequency response characteristics to IEC 60601-1 |
| Alternative Leakage Measurements | |
|---|---|
| Test Voltage | 250V at mains frequency |
| Test Current | 3.5 mA current limited |
| Measurement Range | 4μA to 9999μA |
| Measurement Resolution | 1μA |
| Measurement Accuracy | ±5% of reading + 2 counts |
| Measurement Type | True RMS |
| Measuring Device | As per IEC 60601-1 |
| Power Measurement | |
|---|---|
| Range | 0.1kVA – 4kVA |
| Accuracy | ±10% + 2 counts |
| Mains Outlet Test | |
|---|---|
| Input voltage range | 0-300V AC |
| Max current | 16A |
| Measures | L – E, N – E |
| Accuracy | ± 5% of reading + 2 counts |
| IEC Mains Lead Test | |
|---|---|
| Test Duration | 2s |
| Test | Continuity of all conductors, Insulation and Polarity |
| General Specification | |
|---|---|
| Mains Power | 230V AC ±10%, 50-60Hz +/- 1Hz, 120V AC ±10%, 60Hz +/- 1Hz (USA model) |
| Battery | 6 x 1.5V AA |
| Weights | 1.6 kg / 3.5 lbs including batteries |
| Size | (L x W x D) 270 x 110 x 75 mm / 10.5 x 4 x 3” |
| Operating Conditions | 0’C – 40’C, 32’F – 104’F, 0-90% RH – NC |
| Storage Environment | -15’C – +60’C / 5’F – 140’F |
| Environmental Protection | IP 40 |
| Standard Accessories (supplied with 288+) |
|---|
| Calibration certificate |
| Earth/ground bond test probe with clip |
| Earth/ground bond clip lead |
| Patient Applied part module |
| 10 Applied part adaptors |
| Detachable 2 meter mains cable |
| Bluetooth USB dongle |
| Electronic instruction manual |
| Quick start guide |
| Application software |
